Gear pump
Straight flange RPI2M
Model: RPI2M
Port 1 thread1/2" BSP
Straight flange RPI2M. The pump supplies fluid flow to a hydraulic circuit. Select its drive and connection arrangement from the exact model documentation.
Straight flange. The exact model is listed on page 1.
| Technical specifications | |
| Component type | Gear pump |
| Port 1 thread | 1/2" BSP |
| Equipment family | Accesories |
| Original specifications - unverified | |
| R1 | 1/2'' BSP |
| R2 | M8X20* x4 uds |
| ORing | 25,12 x 1,78 |
| A | 40 |
| B | 58 |
| C | 8,5 |
| E | 60 |
| F | 12 |
| H | 26,5 |
| Length between center | 40 |
