Oleodinamica Marchesini V0824 V-FCR 1T 60 normally open pull/push end-of-stroke valve

Oleodinamica Marchesini V0824 (V-FCR 1T 60) is a normally open pull/push end-of-stroke valve with 3/8 inch BSP main ports. Its factory ratings are 60 l/min maximum flow and 350 bar maximum operating pressure.

The spool can be pulled or pushed to interrupt flow from P to A. The integrated check path permits return flow from A to P when the valve is actuated. Connect P to the directional control valve and A to the circuit or actuator. The spring-return normal state is open.

The cast iron body contains hardened and ground steel internal components and standard BUNA N seals. The local PDF includes the complete relevant manufacturer ratings, hydraulic schematic, original dimensions and any applicable curves. Representative manufacturer product image for the V-FCR 1T series. Refer to the exact article drawing in the local PDF for port and execution details.
