Oleodinamica Marchesini V0416 VBCDF 1/2 SE OMS single motor counterbalance valve

Oleodinamica Marchesini V0416 (VBCDF 1/2 SE OMS) is a single motor counterbalance valve rated for 50 l/min maximum flow and 350 bar maximum operating pressure. Its factory pilot ratio is 1:4.5. The manufacturer lists a standard setting of 320 bar; this catalogue setting is separate from the maximum pressure rating.

The valve controls motor rotation and retains a load in one direction. Connect V1/V2 to the supply and use the original motor-flange connections C1/C2 for the free-flow and controlled sides. The original diagram identifies the controlled return path and the pilot connection.

The direct flange interface is for Danfoss OMS motors. V1/V2 supply connections are 1/2" BSP; the C1/C2 motor-interface passages have a listed 9 mm bore and O-ring sealing. Check the original drawing for the exact mounting pattern.

This unsuffixed article is the version without the /SF brake-release function. The shared factory sheet also illustrates the separately ordered /SF version; its brake connection must not be assigned to this article.

The manufacturer specifies a valve setting at least 1.3 times the load-induced pressure. Check the circuit setting against the actual load; no customer-specific adjustment or /P or /PP option is inferred from this standard article code. The body is zinc-plated steel with hardened and ground steel internals and standard BUNA N seals.

The local PDF preserves the complete relevant manufacturer code table, hydraulic schematic, original drawings, curves and conditions. Representative manufacturer product image for the VBCDF SE OMS series. Check the exact article drawing and hydraulic schematic in the local PDF for its port arrangement and execution.
