Oleodinamica Marchesini R1274 is an OXL extra-long banjo pipe. The exact manufacturer code is listed in the factory OXL range and is offered by an independent distributor as OCCHIO EXTRALUNGO 600 3/8 inch.
The OXL family uses zinc-plated steel banjo-and-pipe fittings to connect DIN 2353 valve-series connections to a cylinder through a matching hollow screw. Orientation is adjusted during assembly; this is not a continuously rotating hydraulic joint.
The supplier designation is retained as a nominal product description. It is not a verified physical overall length or a threaded-port specification. The available factory PDF is a family reference and does not contain a dimension row for R1274. Tube outside diameter, banjo-eye dimensions, mass, operating pressure and burst pressure are not assigned to this article.
Representative manufacturer OXL product image; exact lengths and eye dimensions vary with execution.
Full specifications
Technical specifications
Product type
Extra-long banjo pipe
Mounting
Cylinder mounting with hollow screw
Intended valve family
DIN 2353 valve series; family application reference
