Oleodinamica Marchesini R1120 (NDO 1/4 x 12L) is a zinc-plated steel nipple with nut and olive for hydraulic valve mounting. Its listed mass is 0.06 kg. The local manufacturer sheet includes the complete exact-code table and the corresponding original connection drawing.
The nipple connects a 1/4" BSP male threaded port to 12 mm outside-diameter tubing with the supplied nut and olive. The factory type identifies the 12L execution. Tube diameter is distinct from the BSP port size. The source lists L1 = 11 mm and L2 = 28 mm.
The shared fitting sheet does not specify a pressure rating, flow capacity, seal compound or operating-temperature range for this article. No such values are inferred from other valves or fittings.
The local PDF retains the complete relevant original manufacturer table and drawing. Representative manufacturer product image for the NDO series. Use the exact article drawing in the local PDF to check its connections and mounting arrangement.
