Oleodinamica 2MP DRV-S08-04-220-N-H direct-acting cartridge relief valve

Oleodinamica 2MP DRV-S08-04-220-N-H is a direct-acting screw-in pressure relief cartridge in the DRV-S08-04 family.

It has a 50–220 bar spring adjustment range, NBR seals and hexagonal-head screw adjustment. The cartridge uses 3/4"-16 UNF mounting threads and the C007 cavity.

Flow opens from port 1 to port 2 when inlet pressure exceeds the spring setting. The optional in-line housing is not included. The spring adjustment range does not specify the delivered pressure setting.

Maximum pressure is 350 bar and nominal flow is 30 L/min.
