Valve

NG6 Double check valve in A and B AKV-6-D H

Model: AKV-6-D H
Maximum pressure (bar)315

Description

NG6 Double check valve in A and B AKV-6-D H. The valve controls reverse flow through the stated connection arrangement.

Model specifications: Maximum pressure (bar): 315.

Technical documentation

NG6 Double check valve in A and B. The exact model is listed on page 2.

Full specifications

Technical specifications
Component type Valve
Maximum pressure (bar) 315
Equipment family Modular blocks for NG6
Original specifications - unverified
Max. pressure, bar 315
Flow max, l/min 40
C 46
D 36
E 13
F 34,5
G 40
H 23
L 107
L1 6
L2 6
Size NG-6
