Hydraulic motor

MOMH type motor 32 mm Ø MOMH400

Model: MOMH400
Displacement (cm³/rev)400
Port 1 thread1/2" BSP
Full specifications ↓

Description

MOMH type motor 32 mm Ø MOMH400. The hydraulic motor converts fluid power into rotary motion. Check its drive and connection arrangement.

This engineering record preserves the exact model reference from the source import. Normalized specifications are shown where the primary model row establishes their meaning and units. Original imported specifications are retained separately for review.

Local technical documentation: verification pending.

Full specifications

Technical specifications
Component type Hydraulic motor
Displacement (cm³/rev) 400
Port 1 thread 1/2" BSP
Port 2 thread 1/4" BSP
Documentation status Exact primary-card model confirmed
Equipment family Hydraulic motors
Original specifications - unverified
Max.Peak pressure 200
Displacement, cm3/rev 400
Max. flow cont. 75
Max.torque peak 1.055
Max.torquecont. 825
R1 1/2'' BSP
R2 1/4'' BSP
Max.powercont. 11,5
Max.press.cont. 140
Max.press.interm 170
R.P.M.cont. 185
B 56
L 196
