Directional valve

Joysticks with button and switch (fitting included) HCD4/1 DE

Model: HCD4/1 DE

Description

Joysticks with button and switch (fitting included) HCD4/1 DE. The valve routes fluid through the circuit. Match its actuation and port arrangement to the application.

Technical documentation

Joysticks with button and switch (fitting included). Archived DICSA technical sheet from the 2023 source import. The exact model is listed on page 1. Specifications describe that catalogue revision.

Full specifications

Technical specifications
Component type Directional valve
Equipment family Stackable control valves
Original specifications - unverified
Max. pressure, bar 350
Flow max, l/min 80
R1 1/2''
Levers 1
Type D.E.
Tierodlength 140
X 114
Y 129
