Directional valve

HCD6 type. Manual operator, return to center by spring. Relief valve (without lever) HCD6/1 DE

Model: HCD6/1 DE

Description

HCD6 type. Manual operator, return to center by spring. Relief valve (without lever) HCD6/1 DE. The valve routes fluid through the circuit. Match its actuation and port arrangement to the application.

Technical documentation

HCD6 type. Manual operator, return to center by spring. Relief valve (without lever). The exact model is listed on page 1.

Full specifications

Technical specifications
Component type Directional valve
Equipment family Stackable control valves
Original specifications - unverified
Max. pressure, bar 350
Flow max, l/min 100
R1 1/2''BSP
R2 3/4''BSP
Levers 1
Type D.E.
Tierodlength 180
X 140
Y 156
