Bosch Rexroth MK20G1X/V throttle check valve
Click image to enlarge
Throttle check valve

Bosch Rexroth MK20G1X/V throttle check valve
Model: MK20G1X/V · Bosch Rexroth
Maximum operating pressure (bar)315
Maximum flow (l/min)275
Control functionThrottle check valve
Actuationwith mechanical actuation
Port count2
Mounting interfacePipe thread G1 ISO 228-1
Full specifications ↓ Technical catalog · PDF

Description

MK20G1X/V is a Bosch Rexroth throttle check valve. This throttle check valve regulates flow in one direction and permits free return flow in the opposite direction. Its threaded body is intended for installation in a hydraulic line.

The manufacturer lists a maximum operating pressure of 315 bar and a maximum flow of 275 L/min for this execution.

Mounting: Threaded connection. Seal material: FKM. Spool: A → B. Switching positions: 2.

Full specifications

Technical specifications
Component type Throttle check valve
Maximum operating pressure (bar) 315
Maximum flow (l/min) 275
Port count 2
Mounting interface Pipe thread G1 ISO 228-1
Mounting type Threaded connection
Compatible hydraulic fluids HEES / HEPG / HETG / HFDR / HFDU / HL / HLP / HLPD / HVLP / HVLPD
Equipment family MK
Control function Throttle check valve
Manufacturer Bosch Rexroth
Manufacturer part number R900423328
Spool symbol A → B
Switching position count 2
Nominal size 20
Weight (kg) 2.2
Technical specifications
Actuation with mechanical actuation
Technical specifications
Seal material FKM
