Bosch Rexroth DR6DP2-5X/210YMV direct-operated pressure-reducing valve

DR6DP2-5X/210YMV is the factory-listed direct-operated pressure-reducing valve identified by material number R900435680. This size 6 subplate execution regulates secondary pressure and has internal hexagon with protective cap adjustment, internal pilot-oil supply and external pilot-oil return. Its 210 bar pressure stage is an adjustment endpoint, not a declared factory preset. The existing complete designation specifies FKM seals and no integral check valve.

Use the applicable manufacturer installation, fluid-compatibility and characteristic-curve conditions. Operating ceilings and pressure adjustment stages serve different purposes and must not be treated as a single simultaneous operating point.

Configuration and installation are defined by the corresponding 5X series reference. The pressure-adjustment endpoint alone does not establish maximum inlet pressure or flow; select the hydraulic operating point using the applicable port-specific limits and characteristic curves.
