Valve
Bidirectional flow restrictor valve RCB12
Model: RCB12
Bidirectional flow restrictor valve RCB12. The valve routes fluid through the circuit. Match its actuation and port arrangement to the application.
Bidirectional flow restrictor valve. The exact model is listed on page 1.
| Technical specifications | |
| Component type | Valve |
| Equipment family | "GreenLine" Hydraulic valves |
| Original specifications - unverified | |
| Max. pressure, bar | 315 |
| Flow max, l/min | 185 |
| R1 | 3/4'' BSP |
| D | 38 |
| E | 38 |
| H | 108 |
| L | 78 |
